Planetary Gearboxes Robust and Precise | Delta Line


Planetary gearboxes

Our high-performance planetary gearboxes are designed for robustness, to sustain intermittent or sudden load changes and are ideally suited for precise positioning applications. Our planetary gearheads are available with diameters from 8 to 80mm.



Planetary gearboxes
.

Products
Product finder
Technology:
Category:
More Filters
22JMS
Planetary gearboxes - JMS series
Size (mm) 22
Length (L) (mm) 23,4 - 36,4
Reduction Ratio 3,71 - 138,99
Nominal Output Torque (Nm) 0,6 - 2
28JMS
Planetary gearboxes - JMS series
Size (mm) 28
Length (L) (mm) 29 - 43
Reduction Ratio 3,71 - 138,99
Nominal Output Torque (Nm) 1,2 - 4
36JMS
Planetary gearboxes - JMS series
Size (mm) 36
Length (L) (mm) 27 - 41,1
Reduction Ratio 3,71 - 138,99
Nominal Output Torque (Nm) 2 - 6
42JMS
Planetary gearboxes - JMS series
Size (mm) 42
Length (L) (mm) 31,5 - 52,5
Reduction Ratio 3,71 - 138,99
Nominal Output Torque (Nm) 3 -10
GP42 -S
Planetary gearboxes - GP series
Size (mm) 42
Length (L) (mm) 42,7 - 70,6
Reduction Ratio 3,931 - 240,545
Nominal Output Torque (Nm) 2,88 - 19
Max. Input Speed (rpm) 8236 - 18000
56JMS
Planetary gearboxes - JMS series
Size (mm) 56
Length (L) (mm) 37,8 - 60,8
Reduction Ratio 3,6 - 76,77
Nominal Output Torque (Nm) 9 -30
GP56 -S
Planetary gearboxes - GP series
Size (mm) 56
Length (L) (mm) 50,6 - 67,8
Reduction Ratio 3,293 - 62,326
Nominal Output Torque (Nm) 7,73 - 26,48
Max. Input Speed (rpm) 4658 - 13000
GP56 -N - Low noise
Planetary gearboxes - GP series
Size (mm) 56
Length (L) (mm) 56 - 73
Reduction Ratio 3,24 - 35,05
Nominal Output Torque (Nm) 1,53 - 15,84
Max. Input Speed (rpm) 5450 - 9758
GP56 -T - Torque
Planetary gearboxes - GP series
Size (mm) 56
Length (L) (mm) 54,8 - 86
Reduction Ratio 3,293 - 256,23
Nominal Output Torque (Nm) 7,73 - 35
Max. Input Speed (rpm) 4658 - 13000
GP80 -T - Torque
Planetary gearboxes - GP series
Size (mm) 80
Length (L) (mm) 103,5 - 129
Reduction Ratio 3,33 - 66,62
Nominal Output Torque (Nm) 10,58 - 47,85
Max. Input Speed (rpm) 3184 - 7000
